Enerdrive 12V 2000W 80A Inverter Charger
Enerdrive 12V 2000W 80A Inverter Charger
Out of stock
This product will offer you True Sinewave AC power for your RV, Marine, 4WD and remote power needs, whilst also recharging your battery automatically when 240V AC is available.
The Sinewave Inverter-Charger can run multiple 240V AC-powered appliances when you need AC power off-grid. The multi-stage battery charger offers charging profiles for multiple different types of batteries. The built-in transfer switch will automatically switch between 240V mains supply when available and battery power when 240V mains is not available.
Also included in the unit is a RCD Safety Switch. This switch monitors the flow of electricity through the inverter and detects any problems that may pose a risk to personal safety and switches the output power off within 0.03 of a second.
The 12V 2000W/80A Inverter-Charger is suitable for appliances that use up to 2000W of power for operation, such as induction cooktops, microwaves, coffee machines and more. All ENERDRIVE | DOMETIC branded products are covered by our extensive 5 Year warranty.
Couldn't load pickup availability
Product features
Product features
Seamless 16A AC Internal Transfer Switch
AC RCD/Safety Switch with test button
Remote Control Display Panel
Regulated Pure Sine Wave Output
Quiet Operation
Compact Size for Easy Installation
Variable settings offered for Gel, Flooded, AGM, and Lithium battery compatibility.
Multi-stage charging ensures batteries are charged to their manufacturer’s recommendations.
Lightweight compact design
Built-in load sense to minimize battery drain
Specifications
Specifications
Charger Output Current (Maximum) 80A
AC Output Power 2000W
AC Output Current 8.7A
AC Output Voltage 230VAC
AC Output Waveform True Sinewave (<3% THD)
Nominal DC Input Voltage 12.5Vdc
DC Input Voltage operating range 10.5 – 16.5 VDC
Under Voltage Alarm 11.0 / 12.5 VDC
Under Voltage Shutdown 10.5 / 12.0 VDC
Over Voltage Shutdown 16.5 VDC
AC Transfer Switch Yes
Transfer Time <30ms
Transfer Relay Rating 16A
AC Input socket IEC-C20 16A Heavy Duty Connector
AC Output socket IEC-C19 16A Heavy Duty Connector
Safety and Environmental
Conformance LVD: EN/IEC 62040-1, IEC 61558-2-16
Agency Markings CE
Operating Temperature 0°C to 40°C
Peak Efficiency 90%
Storage Temperature -20°C to 60°C
Relative Humidity 5 - 90% non-condensing
Operating Altitude Up to 3000m above sea level
Weights and Dimensions
Weight 8kg
Dimensions (W x H x D) 307W x 440.7H x 108Dmm
Warranty 5 Years
